Brand Name : BK
Model Number : XTB700HP
Certification : ISO9001/ISO14001
Place of Origin : CHINA
MOQ : 1
Price : Negotiation
Payment Terms : L/C, T/T
Supply Ability : 300 sets / month
Delivery Time : 25 working days after receiving the advance payment
Packaging Details : Exported wooden case
Flow Rate : 239-448 m³/min
Cooling way : Air
Size : W1800mm* D3500mm* H2200mm
Discharge : 500mm
Model : XTB700HP
Weight : 3900 kg
Feature : Max Size
Advantages1 : Remote control, Intelligent control
Advantages2 : High efficiency,Cost low,Energy saving
Machine Introduction
XTB Air Suspension Bearing Centrifugal Blower is an efficient fluid machinery that combines advanced suspension technology and centrifugal Blower principles, widely used in multiple industrial fields.
Product Components
Touch screen LCD | Variable frequency drive | Cooling air muffler |
1,Input driving signal 2,View operational data 3,Change product settings | 1,Change the motor speed according to the PLC value | 1,Saving installation space 2,Two air cooling circulation systems |
Vent valve | Air | Internal Muffler |
1,Empty the air to protect the motor when starting and stopping the blower | 1,Compress the surrounding air and gas | 1,Reduce the noise transmitted to the outside through the motor of the entrance path |
Machine Specifications:
Model | 10 | 20 | 30 | 50 | 75 | 100 | 125 | 150 | 200 | 250 | 300 | 350 | 400 | 500 | 600 | 700 | |
Flow rate (mm Aq) | 6000 | 7.3 | 14.5 | 23.0 | 35.9 | 51.0 | 73.8 | 89.4 | 104.0 | 129.0 | 160 | 198 | 227 | 245 | 316 | 390 | 448 |
8000 | 11.1 | 17.7 | 28.1 | 37.0 | 57.2 | 72.8 | 86.3 | 100.9 | 130 | 156 | 179 | 189 | 256 | 307 | 353 | ||
10000 | 21.8 | 31.0 | 46.8 | 57.2 | 68.6 | 83.2 | 104 | 128 | 147 | 158 | 205 | 252 | 290 | ||||
12000 | 28.0 | 37.4 | 49.9 | 60.3 | 70.2 | 94 | 109 | 125 | 149 | 177 | 207 | 239 | |||||
Discharge(DN) | 80 | 150 | 150 | 150 | 200 | 250 | 250 | 250 | 300 | 350 | 350 | 350 | 400 | 500 | 500 | 500 |
Weight(kg) | 200 | 395 | 400 | 415 | 700 | 780 | 860 | 870 | 920 | 1400 | 1480 | 1500 | 2200 | 3700 | 3860 | 3900 | |
SIZE (mm) | W | 650 | 800 | 800 | 800 | 1020 | 1020 | 1020 | 1020 | 1020 | 1300 | 1300 | 1300 | 1700 | 1800 | 1800 | 1800 |
D | 650 | 1150 | 1150 | 1150 | 1600 | 1600 | 1700 | 1700 | 1700 | 2000 | 2000 | 2000 | 2500 | 3500 | 3500 | 3500 | |
H | 1020 | 1350 | 1350 | 1350 | 1580 | 1580 | 1780 | 1780 | 1780 | 1900 | 1900 | 1900 | 2040 | 2200 | 2200 | 2200 |
Advantages of XTB Blower
①,Simple Maintenance
②,Compact Structure
③,Low noise,no vibration,long service life
④,Convenient usage and control
⑤,Oil free,no vibration,air bearing
⑥,High efficiency,saving energy
Our Company and Patents
![]() |
